Chapter 1. Programming in Processing
Introduction
This introduction is based on Daniel Shiffman's tutorial .
is a language and development environment oriented toward . In the course Media Processing in
Processing (MPP), processing is one of the main instruments used to introduce some
fundamentals in sound and image processing. Processing is an extension of Java that supports
many Java structures with a simplified syntax.
Processing can be used in three
Basic : Sequence of commands for simple drawing by graphic primitives. --
Table 1.1.
size(256,256);
background(0);
stroke(255);
ellipseMode(CORNER);
ellipse(72,100,110,130);
triangle(88,100,168,100,128,50);
without stroke(140);
strokeWeight(4);
line(96,150,112,150);
line(150,150,166,150);
line(120,200,136,200);
Intermediate : Procedural programming --
Table 1.2.
void setup() {
size(256,256);
applet triangle(88,100,168,100,128,50);
Complex : Object-Oriented Programming (Java) --
color tempcolor = color(255,0,0);
pinocchio = new Puppet(tempcolor);
with
colore = c_;
colored }
void draw () {
nose
stroke(255);
strokeWeight(1);
ellipseMode(CORNER);
ellipse(72,100,110,130);
stroke(colore);
beginShape(TRIANGLES);
vertex(114, 180);
vertex(mouseX, mouseY);
vertex(140, 180);
endShape();
strokeWeight(4);
line(96,150,112,150);
line(150,150,166,150);
}
}
The Processing programs can be converted into Java applets. In order to do that, one just goes to
the File menu and chooses Export. As a result, five files will be created and put in an applet
folder:
index.html: html code to visualize the applet
filename.jar: the compiled applet, including all data (images, sounds, etc.)
filename.pde: the Processing source code
filename.java: the Java code embedding the Processing source code
loading.gif: an image to be displayed while the applet is being loaded.
Moreover, by means of Export Application it is possible to generate an executable application
for Linux, MacOS, or Windows platforms.
Data Types
Variables
A variable is a pointer to a memory location, and it can refer either to primitive values (int,
float, ecc.) or to objects and arrays (tables of primitive-type elements).
The operation of assignment b = a produces
The copy of the content of a into b, if the variables refer to primitive types.
The creation of a new reference (pointer) to the same object or array, if the variables refer to
objects or arrays.
To have a clear understanding of computer science terms such as those that follow, we
recommend looking at Wikipedia
Definition: scope
within a program, it is a region where a variable can be accessed and its value modified
Definition: global scope
defined outside the methods setup() and draw(), the variable is visible and usable anywhere in
the program
Definition: local scope
defined within a code block or a function, the variable takes values that are local to the block or
function, and any values taken by a global variable having the same name are ignored.
Example 1.1. Array declaration and allocation
int[] arrayDiInteri = new int[10];
Programming Structures
Conditional Instructions
if:
if (i == NMAX) {
println("finished");
}
else {
i++;
}
Iterations
while:
int i = 0; //integer counter
while (i < 10) { //write numbers between 0 and 9
println("i = "+ i);
i++;
}
for:
for (int i = 0; i < 10; i++) { //write numbers between 0 and 9
println("i = "+ i);
}
Example 1.2. Initializing a table of random numbers
int MAX = 10;
float[] tabella = new float[MAX];
for (int i = 0; i < MAX; i++)
tabella[i] = random(1); //random numbers between 0 and 1
println(tabella.length + " elements:");
println(tabella);
Functions
Functions allow a modular approach to programming. In Processing, in the intermediate
programming mode, we can define functions other than setup() and draw(), usable from
within setup() and draw().
Example 1.3. Example of function
int raddoppia(int i) {
return 2*i;
}
A function is characterized by the entities (with reference to the example) : return type (int)
name (raddoppia)
parameters (i)
body (return 2*i)
Objects and Classes
A class is defined by a set of data and functions. An object is an instance of a class. Vice versa, a
class is the abstract description of a set of objects.
For an introduction to the concepts of object and class see Objects and Classes.
Example 1.4. Example of class
Dot myDot;
void setup() {
size(300,20);
colorMode(RGB,255,255,255,100);
color tempcolor = color(255,0,0);
myDot = new Dot(tempcolor,0);
}
void draw() {
background(0);
myDot.draw(10);
}
class Dot
{
color colore;
int posizione;
//****CONSTRUCTOR*****//
Dot(color c_, int xp) {
colore = c_;
posizione = xp;
}
void draw (int ypos) {
rectMode(CENTER);
fill(colore);
rect(posizione,ypos,20,10);
}
}
A class is characterized by the following entities (with reference to the example) : name (Dot)
data (colore, posizione)
constructor (Dot())
functions (or methods, draw())
An object (instance of a class) is declared in the same way as we declare a variable, but we have to
allocate a space for it (as we did for the arrays) by means of its constructor (with reference to the
Declaration: (Dot myDot;)
Allocation: (myDot = new Dot(tempcolor,0))
Use: (myDot.draw(10);)
For a quick introduction to the Java syntax see Java Syntax Primer
With the following draw() method we want to paint the window background with a gray whose
intensity depends on the horizontal position of the mouse pointer.
void draw() {
background((mouseX/100)*255);
}
However, the code does not do what it is expected to do. Why?
The variable mouseX is of int type, and the division it is subject to is of the integer type. It is
necessary to perform a from int to float by means of the instruction (float)mouseX.
What does the following code fragment print out?
int[] a = new int[10];
a[7] = 7;
int[] b = a;
println(b[7]);
b[7] = 8;
println(a[7]);
int c = 7;
int d = c;
println(d);
d = 8;
println(c);
7
8
7
7
The following sketch generates a set of 100 moving circles and draws all chords linking the
intersection points of all couples of intersecting circles.
/*
Structure 3
A surface filled with one hundred medium to small sized circles.
Each circle has a different size and direction, but moves at the same slow rate.
Display:
A. The instantaneous intersections of the circles
B. The aggregate intersections of the circles
Implemented by Casey Reas <http://groupc.net>
8 March 2004
Processing v.68 <http://processing.org>
modified by Pietro Polotti
28 March, 2006
Processing v.107 <http://processing.org>
*/
int numCircle = 100;
Circle[] circles = new Circle[numCircle];
void setup()
{
size(800, 600);
frameRate(50);
for(int i=0; i<numCircle; i++) {
circles[i] = new Circle(random(width),
(float)height/(float)numCircle * i,
int(random(2, 6))*10, random(-0.25, 0.25),
random(-0.25, 0.25), i);
}
ellipseMode(CENTER_RADIUS);
background(255);
}
void draw()
{
background(255);
stroke(0);
for(int i=0; i<numCircle; i++) {
circles[i].update();
}
for(int i=0; i<numCircle; i++) {
circles[i].move();
}
for(int i=0; i<numCircle; i++) {
circles[i].makepoint();
}
noFill();
}
class Circle
{
float x, y, r, r2, sp, ysp;
int id;
Circle( float px, float py, float pr, float psp, float pysp, int pid ) {
x = px;
y = py;
r = pr;
r2 = r*r;
id = pid;
sp = psp;
ysp = pysp;
}
void update() {
for(int i=0; i<numCircle; i++) {
if(i != id) {
intersect( this, circles[i] );
}
}
}
void makepoint() {
stroke(0);
point(x, y);
}
void move() {
x += sp;
y += ysp;
if(sp > 0) {
if(x > width+r) {
x = -r;
}
} else {
if(x < -r) {
x = width+r;
}
}
if(ysp > 0) {
if(y > height+r) {
y = -r;
}
} else {
if(y < -r) {
y = height+r;
}
}
}
}
void intersect( Circle cA, Circle cB )
{
float dx = cA.x - cB.x;
float dy = cA.y - cB.y;
float d2 = dx*dx + dy*dy;
float d = sqrt( d2 );
if ( d>cA.r+cB.r || d<abs(cA.r-cB.r) ) {
return; // no solution
}
// calculate the two intersections between the two circles cA and cB, //
// whose coordinates are (paX, paY) and (pbX, pbY), respectively. //
stroke(255-dist(paX, paY, pbX, pbY)*4);
line(paX, paY, pbX, pbY);
}
1. Complete the missing part that is expected to compute the intersections of the circles, in such
a way to draw the chords linking the intersection points. It is possible to use the computation
of intersection coordinates in a ad-hoc reference system (), then converting the result into the
Processing window coordinate system.
2. Make the chords time-variable by giving different speeds to different circles.
/*
Structure 3 <
